Ingress vs LoadBalancer

When deploying applications in Kubernetes, exposing your services to external users becomes a key requirement. Two commonly used methods to achieve this are:

• LoadBalancer Services
• Ingress Controllers

Although both provide access to your Kubernetes applications from outside the cluster, they work in different ways and serve different purposes. In this post, we’ll explore what each is, how they work, and when to use them — complete with examples.

LoadBalancer

A LoadBalancer type service in Kubernetes provisions an external load balancer (via your cloud provider) and assigns a public IP to your service. This is the easiest way to expose a single service to the internet.

Example: LoadBalancer Service

Suppose you have a simple web application running in a Kubernetes cluster:

apiVersion: v1
kind: Service
metadata:
  name: my-web-service
spec:
  selector:
    app: my-web-app
  ports:
    - protocol: TCP
      port: 80
      targetPort: 8080
  type: LoadBalancer

How it Works

• Kubernetes contacts the cloud provider’s API to create a cloud load balancer (like AWS ELB, GCP’s Load Balancer).
• This load balancer gets a public IP and routes external traffic to your service.
• Traffic from the load balancer is routed to one of the pods behind the service.

Pros

• Easy to set up.
• Great for exposing a single service.
• Direct integration with cloud provider load balancers.

Cons

• Each service of type LoadBalancer provisions a new external load balancer — expensive!
• Doesn’t support path-based routing, SSL termination, etc.

Ingress

Ingress is an API object that manages external access to services in a cluster, typically via HTTP/HTTPS. You configure routing rules based on the request host and path.

Components

1. Ingress Resource: Defines rules (e.g., route /api to Service A, /web to Service B).
2. Ingress Controller: Software that reads the Ingress rules and configures a reverse proxy (e.g., NGINX, Traefik) accordingly.

Example: Ingress with NGINX

Let’s assume two services: api-service (on port 8080) and web-service (on port 8081).

Deploy the Ingress Resource:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  rules:
    - host: myapp.example.com
      http:
        paths:
          - path: /api
            pathType: Prefix
            backend:
              service:
                name: api-service
                port:
                  number: 8080
          - path: /web
            pathType: Prefix
            backend:
              service:
                name: web-service
                port:
                  number: 8081

Make sure you have an Ingress Controller (like NGINX) installed and running.

How it Works

• The Ingress Controller listens for changes in Ingress resources.
• It configures its reverse proxy to route traffic based on the rules.
• A single LoadBalancer or NodePort exposes the Ingress Controller, and it handles internal routing.

Pros

• Efficient: One LoadBalancer serves many services.
• Supports advanced routing (path/host-based), TLS termination.
• Easy to manage multiple services under the same domain.

Cons

• Requires setting up and managing an Ingress Controller.
• Slightly more complex for beginners.
• Not ideal for non-HTTP traffic.

Ingress vs LoadBalancer: Side-by-Side Comparison

When Should You Use Each?

Use LoadBalancer when:

• You need to expose a single service quickly.
• You’re dealing with non-HTTP traffic (TCP, UDP).
• You don’t want to manage an Ingress Controller.

Use Ingress when:

• You need path-based or host-based routing.
• You want to expose multiple services via one LoadBalancer.
• You need TLS/SSL termination centrally.
• You want cost savings on public IPs.

Real-World Example Use Case

Let’s say you are building a SaaS platform:

• api.myapp.com → Backend APIs
• web.myapp.com → Frontend
• admin.myapp.com → Admin portal

Using a LoadBalancer for each would result in 3 separate public IPs and load balancers, which is expensive.

With Ingress, you can route all this through one NGINX Ingress controller, manage TLS in one place, and save cost.

Final Thoughts

Both LoadBalancer and Ingress serve the same end goal — exposing Kubernetes services externally — but they cater to different needs. If you’re starting small or handling simple services, LoadBalancer is straightforward. But as your platform grows, Ingress offers the scalability, flexibility, and cost-efficiency you’ll likely need.
